Stop replacing reliability with guesswork. This industrial DPDT relay delivers precise control and consistent switching performance for high-demand electrical systems, supporting service environments that require predictable uptime and repeatable operation. Designed for trained technicians, the relay fits control panels where exact coil and contact specifications matter most.
LongDescription#@#NA#@@#Cleaning Instructions#@#Wipe relay housing and mounting surfaces with a mild detergent and damp cloth; avoid soaking electrical contacts. Use isopropyl wipes on high-touch zones like panel knobs, chair backs, menu covers, and door handles to remove oils and reduce Norovirus and cold-virus transfer. Sanitize visibly so inspectors see compliance. Remove food residue under shelves and booths to deter pests. Dry parts before reinstallation to prevent corrosion and extend service life.#@@#Additional Info#@#PartsTown AVTELRLY0310 EL RLY0310 is a DPDT relay (Tyco K10P‑11AT5‑120) rated 15A for control circuits in kitchen equipment; it measures 4.85" x 2.1" x 1.95" and weighs 0.09 pounds, with CSA recognition for reliable performance.#@@#General Info#@#Description #@#
Stop replacing reliability with guesswork. This industrial DPDT relay delivers precise control and consistent switching performance for high-demand electrical systems, supporting service environments that require predictable uptime and repeatable operation. Designed for trained technicians, the relay fits control panels where exact coil and contact specifications matter most.
#@@# Coil Voltage Accuracy#@#
Specify coil voltage precisely to match control circuits and avoid nuisance trips. The relay uses a 120-volt coil rating that integrates with standard control transformers, reducing the need for custom wiring or voltage conversion.
#@@# Dual Pole Switching#@#
Handle two isolated circuits with a single compact device to simplify panel layouts and reduce component count. The DPDT configuration enables simultaneous control of separate loads, allowing coordinated sequencing of heaters, motors, or indicators.
#@@# Rated Current Capacity#@#
Rely on a 15 amp contact rating to manage moderate load currents common in commercial kitchen controls and equipment. The rating supports resistive and light inductive loads within specified duty cycles without excessive derating.
#@@# Compact Form Factor#@#
Install the relay within tight electrical enclosures thanks to a footprint measuring approximately 4.85 inches by 2.1 inches by 1.95 inches, permitting denser component placement and conserving cabinet space. The small weight of about 0.09 pounds eases handling during retrofit and maintenance tasks.
#@@# Industry Compatibility#@#
Use a design aligned with established relay families, ensuring interchangeability with common socket and mounting standards for streamlined field replacement. Technicians benefit from familiar terminal arrangements that accelerate troubleshooting and reduce downtime.
#@@# Traceable Identification#@#
Maintain inventory control and warranty support with manufacturer and part identifiers embedded in documentation and labeling for procurement teams.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Inspect the relay monthly for corrosion, loose terminals, and discoloration; replace units that show pitting or heat damage. De-energize circuits and verify coil resistance with a multimeter before service. Tighten terminal screws to manufacturer torque and apply contact cleaner rated for electrical components. Mount the relay on a vibration-isolating bracket and ensure ventilation clears 1 inch around the device. Record maintenance actions and part number AVTELRLY0310 for traceability.
