Stop using makeshift fixes for worn hinge components. This hinge cartridge provides engineered alignment, consistent motion, and field-replaceable serviceability to restore door performance in high-usage environments. Designed for professional kitchens and high-traffic utility areas, this part offers precise dimensions and manageable weight for rapid installation and reliable operation.
LongDescription#@#NA#@@#Cleaning Instructions#@#Wipe hinge cartridge with a soft cloth and mild detergent; rinse and dry immediately to prevent corrosion. Use a non-abrasive brush for crevices and compress air to remove debris. Apply a light machine-grade lubricant monthly to pivot points and operate hinge to distribute oil. Inspect fasteners weekly and tighten as needed. Cleaning prevents contamination of high-touch zones and preserves hardware appearance and function.#@@#Additional Info#@#PartsTown 178CARTRIDGE hinge cartridge offers a durable stainless steel pivot assembly for kitchen doors, measuring 5.85" L, 3.55" W, 1.85" H, and weighing 0.53 lbs. It installs with standard fasteners to restore hinge alignment.#@@#General Info#@#Description #@#
Stop using makeshift fixes for worn hinge components. This hinge cartridge provides engineered alignment, consistent motion, and field-replaceable serviceability to restore door performance in high-usage environments. Designed for professional kitchens and high-traffic utility areas, this part offers precise dimensions and manageable weight for rapid installation and reliable operation.
#@@# Dimensions Controlled#@#
The unit measures 5.85 inches long, 3.55 inches wide, and 1.85 inches high, simplifying fit checks and reducing installation time. Technicians find that predictable sizing eliminates trial fits and minimizes downtime during service windows.
#@@# Lightweight Serviceability#@#
Weighing just 0.53 pounds, the cartridge allows for single-technician handling and quick swaps on heavy doors or panels. Its reduced mass lowers the risk of strain during repeated maintenance cycles and supports faster turnaround on scheduled repairs.
#@@# Consistent Hinge Function#@#
Engineered as a cartridge replacement, this component restores smooth pivot action and maintains alignment under frequent cycling. Operators report stable door motion across repeated open and close cycles, which helps maintain safety and user experience in busy facilities.
#@@# Field Replaceable Design#@#
Technicians can quickly replace the cartridge through a configuration that isolates the hinge mechanism from adjacent hardware. The replacement procedures involve minimal steps, shortening service calls and preserving adjacent mounting surfaces from unnecessary disturbance.
#@@# Material and Durability#@#
Manufactured to PartsTown specifications and supplied under part number ADVA178CARTRIDGE, this cartridge uses construction suited for commercial use and resists wear typical in institutional settings. Maintenance teams appreciate its predictable life expectancy and reduced frequency of emergency interventions.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Inspect the 178CARTRIDGE hinge cartridge monthly and tighten mounting fasteners to maintain alignment. Remove debris and apply a light food-safe lubricant to pivot points every 90 days. Replace seals or worn components when excessive play or noise appears. Record service dates and parts replaced to track lifecycle. Calibrate door closing torque after reassembly to prevent stress on adjacent hardware and ensure consistent operation.
