Dependable cooling performance meets straightforward serviceability in this motor designed for evaporator fans in commercial refrigeration systems. Technicians gain consistent 120V counterclockwise operation that integrates with a wide range of units, while facilities reduce downtime through a component engineered for frequent cycles and continuous use. Engineers specify this motor when reliable airflow, compact dimensions, and compatibility with standard fan assemblies matter most.
LongDescription#@#NA#@@#Cleaning Instructions#@#Clean the evaporator fan motor (EL MTR0230) after power-off. Remove debris, vacuum fins, and wipe housing with a damp cloth and mild detergent. Use a non-corrosive lubricant on bearings per manufacturer specs. Inspect wiring and mounting; tighten fasteners. Sanitize nearby high-touch items—menu covers, chair backs, shakers—to stop germ transfer and shape customer perception. Regular cleaning prevents pest attraction and helps meet visible health-code expectations.#@@#Additional Info#@#PartsTown EL MTR0230 evaporator fan motor operates at 120V CCW and fits #301-6816, providing airflow for refrigeration systems; it weighs 1.38 pounds and measures 4.9 by 4.6 by 4.4 inches, meeting CSA criteria for foodservice maintenance.#@@#General Info#@#Description #@#
Dependable cooling performance meets straightforward serviceability in this motor designed for evaporator fans in commercial refrigeration systems. Technicians gain consistent 120V counterclockwise operation that integrates with a wide range of units, while facilities reduce downtime through a component engineered for frequent cycles and continuous use. Engineers specify this motor when reliable airflow, compact dimensions, and compatibility with standard fan assemblies matter most.
#@@# Compact Footprint#@#
Compact dimensions of 4.9 inches in length, 4.6 inches in width, and 4.4 inches in height permit installation in tight evaporator housings and allow for straightforward replacement in confined racks. Technicians achieve proper fit without extensive modification to mounting brackets or ductwork.
#@@# 120V Counterclockwise#@#
This motor operates on a 120V electrical supply and rotates counterclockwise, matching orientation requirements for many evaporator fan applications. Electricians verify wiring compatibility quickly, minimizing labor time during swapouts.
#@@# Continuous Duty Rating#@#
Manufacturers build the unit for continuous operation in commercial refrigeration environments, supporting prolonged run times common in food service and hospitality facilities. Managers expect stable airflow and reduced temperature variance when refrigeration systems keep motors running.
#@@# Serviceable Design#@#
Technicians access terminals and mounting points without dismantling adjacent components, simplifying routine inspection and replacement tasks. Maintenance teams complete interventions faster, restoring system airflow with minimal interruption to kitchen operations.
#@@# Balanced Performance#@#
Engineers balance torque and RPM to sustain consistent airflow while managing current draw for efficient electrical use under load. Facility operators observe steady cooling capacity and avoid frequent cycling that stresses compressors.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Inspect EL MTR0230 MOTOR assemblies monthly and disconnect power before service. Remove debris from fan blades and housing using compressed air and a soft brush. Lubricate motor bearings with manufacturer-recommended oil every 3 months. Verify electrical connections for corrosion and tighten terminals to manufacturer torque. Measure rotor current and rotation direction to confirm CCW operation. Replace damaged capacitors or mounts immediately to prevent failure.
