Stop compromising control for convenience. This 24 volt DC transformer supplies consistent low-voltage power for commercial die light installations, supporting up to 35 fixtures from a single 100 watt unit. Installers receive a compact, code-ready power source that accepts 120-277 volt input and mounts in tight wall spaces with minimal clearance.
LongDescription#@#NA#@@#Cleaning Instructions#@#Clean high-touch zones like menu covers, shakers, chair backs, and bathroom handles daily to prevent germ transfer and contamination of food areas. Use a food-safe disinfectant, follow label contact time, and apply with a microfiber cloth. Remove spills and crumbs from booth crevices and under shelves to deter pests. Inspect surfaces before service and maintain visible cleanliness to meet health-code expectations and preserve furnishings' condition.#@@#Additional Info#@#Advance Tabco’s SU-BDT-100 24V DC transformer supports SU-BDL bar die lights, delivers 100 watts from 120-277V input, powers up to 35 lights, mounts in dry locations, and requires 2" clearance on all sides except the mounting face.#@@#General Info#@#Description #@#
Stop compromising control for convenience. This 24 volt DC transformer supplies consistent low-voltage power for commercial die light installations, supporting up to 35 fixtures from a single 100 watt unit. Installers receive a compact, code-ready power source that accepts 120-277 volt input and mounts in tight wall spaces with minimal clearance.
#@@# Power Range#@#
Accepts 120-277 volts at 60 hertz and operates on single phase input, enabling compatibility with typical commercial electrical systems. Installers can use a wide input range to simplify wiring across facilities without additional converters.
#@@# Output Capacity#@#
Delivers 24 volt DC at a rated 100 watt output and supports up to thirty-five lights, providing predictable load handling for medium-length runs. Electricians achieve consistent illumination planning because the unit specifies both wattage and maximum fixture count.
#@@# Mounting Flexibility#@#
Allows vertical or horizontal wall mounting in dry locations and requires a two inch free air clearance on all sides except the mounting face. Technicians gain flexible placement options and can adapt installation to existing backdrops while maintaining ventilation requirements.
#@@# Installation Notes#@#
Ships supplied loose and installs as part of a die wall assembly; the unit does not include die wall wiring or field wiring materials. Project managers allocate wiring labor and materials separately while ensuring the transformer integrates with the overall modular bar system.
#@@# Certifications And Safety#@#
Lists CSA certification and meets standard commercial safety criteria for indoor electrical components, supporting compliance with facility inspection protocols. Maintenance teams can reference certification during audits and documentation.
#@@# Physical Attributes#@#
Measures approximately 15 inches wide, 4 inches high, and 4 inches deep, weighing about 3 pounds, yielding a small footprint for crowded utility areas.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Service technicians should inspect the Advance Tabco SU-BDT-100 transformer monthly for dust and secure mounting. Remove power before cleaning; use compressed air to clear vents and a dry cloth for external surfaces. Verify 2" free air clearance on all sides except the mounting face and confirm vertical or horizontal orientation in a dry location. Test output voltage at 24 volts DC and confirm wiring integrity after any service. Replace if heating exceeds rated 100 watt load.
