Stop risking service interruptions when control circuits fail. This relay and overload assembly provides robust protection for compressors and motors in commercial refrigeration and cooking equipment, combining precise trip response with compact packaging to restore safety and uptime quickly. Technicians will appreciate the straightforward fit dimensions and the reliable electrical characteristics that simplify repairs and reduce downtime.
LongDescription#@#NA#@@#Cleaning Instructions#@#Use a damp microfiber cloth and a mild detergent to wipe relay/overload housings, terminals, and surrounding panels. Apply a disinfectant approved for non-food-contact surfaces on high-touch zones such as cover screws, access handles, and nearby chair backs or door handles. Rinse cloth frequently and let components air dry before re-energizing. Clean weekly or after visible soil to prevent contamination transfer, deter pests, and extend serviceable life of fittings.#@@#Additional Info#@#PartsTown AHT247186 relay/overload replaces failed compressor protection with a compact module (5" L, 7.15" W, 1.65" H, 0.11 lbs); technicians install it to restore motor start and overload protection quickly, CSA compatible.#@@#General Info#@#Description #@#
Stop risking service interruptions when control circuits fail. This relay and overload assembly provides robust protection for compressors and motors in commercial refrigeration and cooking equipment, combining precise trip response with compact packaging to restore safety and uptime quickly. Technicians will appreciate the straightforward fit dimensions and the reliable electrical characteristics that simplify repairs and reduce downtime.
#@@# Relay Functionality#@#
Engineered to cycle control signals with consistent contact integrity, this relay supports switching loads common in kitchen equipment. Installers achieve consistent operation thanks to standardized terminal spacing and predictable actuation thresholds.
#@@# Overload Protection#@#
Integrated overload sensing prevents motor damage by tripping on sustained overcurrent conditions and delaying restart to allow thermal recovery. Maintenance teams benefit from this protective staging that reduces compressor replacements and limits collateral damage.
#@@# Compact Dimensions#@#
Measuring approximately 5 inches long by 7.15 inches wide and 1.65 inches high, the unit fits into tight control compartments. End users gain installation flexibility, enabling retrofits in older cabinets and modern systems without major panel modifications.
#@@# Lightweight Construction#@#
Weighing about 0.11 pounds, the assembly minimizes added strain on mounting clips and harnesses. Service personnel can maneuver components during replacement with reduced risk of connector stress or misalignment.
#@@# Compatibility Range#@#
Designed for use across multiple equipment platforms, this part matches common mounting patterns and electrical requirements in commercial kitchens. Procurement managers reduce SKU complexity by stocking a part that addresses a wide span of service calls.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Inspect the relay/overload assembly monthly for discoloration, odor, or corrosion. Remove power and verify lockout/tagout before servicing. Clean terminals with a noncorrosive contact cleaner and nylon brush; torque screws as per manufacturer specs. Replace components showing pitting or overheating. Verify coil resistance with a calibrated multimeter against factory values. Record service dates, part UID AHT247186, and CSA compliance documentation.
