Stop sacrificing uptime for mismatched parts. This sheave delivers precision alignment and dependable rotational control for industrial kitchen equipment, allowing technicians to restore service quickly and maintain consistent motor loads. Facility maintenance teams and kitchen operators will find the dimensional accuracy and balanced construction simplify refits and reduce vibration during operation.
LongDescription#@#NA#@@#Cleaning Instructions#@#Wipe the sheave with a soft cloth and a neutral detergent solution; rinse with clean water and dry immediately. Remove debris from the bore and keyways using a nylon brush. Inspect for wear, cracks, or corrosion each service interval and replace if dimensions exceed manufacturer tolerance. Clean high-touch surfaces around the part—menu covers, handles, booth backs—to prevent germ transfer and shape customer perception, maintaining CSA and health-code readiness.#@@#Additional Info#@#PartsTown CHA100446 sheave AK 30 with 1/2" bore fits commercial kitchen pulley systems, measuring 3.17" length, 3.16" width, 1.3" height, and weighing 1.32 pounds; CSA-compliant materials ensure reliable belt alignment and reduced vibration.#@@#General Info#@#Description #@#
Stop sacrificing uptime for mismatched parts. This sheave delivers precision alignment and dependable rotational control for industrial kitchen equipment, allowing technicians to restore service quickly and maintain consistent motor loads. Facility maintenance teams and kitchen operators will find the dimensional accuracy and balanced construction simplify refits and reduce vibration during operation.
#@@# Diameter Accuracy#@#
Engineers specify a 3.17-inch outside dimension to match driven pulley geometry and maintain belt tracking. Technicians achieve repeatable tension settings because the part tolerances keep center distances within design limits.
#@@# Bore Compatibility#@#
Designed with a 0.5-inch bore, the component accepts standard shafts used in many countertop mixers and conveyor drives. Mechanics can install the sheave without machining when equipment shafts conform to common commercial sizes.
#@@# Weight and Balance#@#
Weighing 1.32 pounds, the unit provides mass consistent with typical small drive pulleys, minimizing inertial mismatch that causes oscillation. Fitters notice reduced startup torque spikes and smoother acceleration when replacing worn sheaves with this assembly.
#@@# Compact Profile#@#
With a height of 1.3 inches and a width of 3.16 inches, the part occupies minimal axial space, enabling use in confined housings and tight drive layouts. Designers can integrate the sheave into retrofit kits where clearance limits prevent larger components.
#@@# Material Performance#@#
Manufacturers mold the component from durable materials selected for wear resistance and dimensional stability under thermal cycling. Maintenance crews report longer service intervals and less frequent belt realignment when components resist groove wear.
#@@# Compliance and Traceability#@#
Parts carry manufacturer part number CHA100446 and trace back to a known supplier established in 1998, supporting B2B procurement controls and asset records.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Maintain the 100446 SHEAVE AK 30 1/2 BORE by inspecting the bore and flange weekly for wear and scoring. Lubricate bearings with specified grease every 250 operating hours and monitor torque on mounting fasteners after lubrication. Clean debris and residue with a solvent-safe cloth; avoid abrasive tools. Verify alignment with mating shafts and adjust set screws to manufacturer torque. Document service dates and parts replaced for CSA compliance.
