The DPDT micro switch rated at 20A ensures reliable control for compact, durable commercial equipment. Designed for space-limited applications requiring robust electrical performance, this double-pole double-throw switch enables precise circuit selection while maintaining a small footprint, supporting technicians in high-demand food service and hospitality environments.
LongDescription#@#NA#@@#Cleaning Instructions#@#Wipe high-touch items—menu covers, salt/pepper shakers, chair backs, and door handles—daily with a detergent solution, then sanitize contact points with an EPA-registered disinfectant per label contact time. Clean dining surfaces and booth crevices after each shift, removing crumbs and spills to deter pests and prevent stains. Inspect and wipe shelving and floors weekly to stay inspection-ready and maintain furnishings’ condition.#@@#Additional Info#@#PartsTown HT02.19.193.00 is a DPDT micro switch rated 20A, measuring 1.75" x 1.25" x 0.65", weighing 0.07 pounds; ideal for compact control panels and equipment in culinary and commercial settings.#@@#General Info#@#Description #@#
The DPDT micro switch rated at 20A ensures reliable control for compact, durable commercial equipment. Designed for space-limited applications requiring robust electrical performance, this double-pole double-throw switch enables precise circuit selection while maintaining a small footprint, supporting technicians in high-demand food service and hospitality environments.
#@@# Compact Form Factor#@#
Measuring 1.75 inches long, 1.25 inches wide, and 0.65 inches high, the unit fits confined control modules and tight panel cutouts. Its size minimizes enclosure redesign and preserves internal layouts for other components.
#@@# High Current Rating#@#
Built for 20A operation, the switch handles higher-load circuits typical in commercial kitchen controls and machinery. Operators can manage substantial currents without adding parallel contacts or relays, simplifying system design.
#@@# Double-Pole Double-Throw Design#@#
The DPDT setup controls two circuits simultaneously, enabling reversible motor control or multi-circuit switching via one actuator. Maintenance teams gain flexibility for failover paths or power rerouting during service.
#@@# Micro Actuation Mechanism#@#
The micro switch mechanism ensures tactile operation with rapid make-and-break action, enhancing response times for automated controls and safety interlocks. Systems relying on quick, repeatable switching benefit from consistent contact performance.
#@@# Lightweight Construction#@#
Weighing 0.07 pounds, the switch adds minimal mass to assemblies, reducing stress on mounting hardware and actuator linkages. Installers can mount multiple units without affecting equipment balance or handling.
#@@# PartsTown Sourcing#@#
Available through PartsTown with Manufacturer Part Number HT02.19.193.00 and catalog identifier 02.19.193.00, the component integrates seamlessly into parts management workflows for procurement and inventory tracking. Technicians can match the part number for replacements and documentation.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#To maintain the 02.19.193.00 DPDT micro switch (20A), inspect contacts monthly for damage and replace if resistance exceeds specs. De-energize circuits, verify lockout/tagout, clean terminals with non-corrosive cleaner, and use a soft brush for debris. Avoid plastic-degrading solvents. Check actuator alignment, secure hardware, record actions, and test continuity after reassembly.
