Stop sacrificing flow control for fit. This equal elbow connector delivers precise 90-degree routing for 1/4" OD tubing while maintaining leak-free performance under continuous dispensing conditions. Engineers designed the part to allow quick push-in connections and reliable retention, minimizing downtime during installation or service.
LongDescription#@#NA#@@#Cleaning Instructions#@#Unplug system and depressurize lines. Remove connector and inspect for wear. Clean elbow with food-safe detergent and warm water; use a soft brush to remove debris from internal bore. Rinse thoroughly and air dry or use lint-free cloth. Reinstall using compatible 1/4" OD tubing and verify seals. Sanitize contact surfaces with CSA-approved sanitizer per label. Maintain routine cleaning to prevent contamination, grease buildup, equipment failure, and inspection failures.#@@#Additional Info#@#Micro Matic PI0308S John Guest elbow connector accepts 1/4" OD tubing and offers a 90° flow path for beverage systems, ensuring secure push-fit connections and corrosion resistance for bars and kitchens.#@@#General Info#@#Description #@#
Stop sacrificing flow control for fit. This equal elbow connector delivers precise 90-degree routing for 1/4" OD tubing while maintaining leak-free performance under continuous dispensing conditions. Engineers designed the part to allow quick push-in connections and reliable retention, minimizing downtime during installation or service.
#@@# Push-In Connection#@#
The connector uses a John Guest style push-in fitting for rapid, tool-free assembly. Technicians achieve secure seals instantly, reducing labor time and limiting service interruptions.
#@@# 90-Degree Routing#@#
The elbow shape provides a compact directional change that preserves line integrity in confined spaces. Installers avoid sharp bends that can restrict flow and cause pressure loss.
#@@# Corrosion-Resistant Construction#@#
The manufacturer specifies materials compatible with common kegs and draft fluids to resist corrosion in refrigerated environments. Maintenance teams can extend service intervals and avoid premature part replacement.
#@@# Compact Footprint#@#
The small form factor fits tight manifolds, towers, and under-sink assemblies without rework. Designers maintain clean routing and simplify cabinet layouts in high-density installations.
#@@# Compatible With 1/4" Tubing#@#
The fitting accepts 1/4" OD tubing for standard draft and low-pressure lines, ensuring broad compatibility across dispensing systems. Operators retain system flexibility when swapping lines or components.
#@@# Service-Friendly Design#@#
The push-fit retention ring allows straightforward removal and reinstallation during routine preventive maintenance. Field crews can complete line changes quickly, lowering labor costs and reducing outage time.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Inspect the PI0308S elbow weekly for leaks and secure fittings with a calibrated wrench to 8–10 ft·lb. Flush connected tubing with potable water after daily service to remove sediment and prevent microbial growth. Disassemble John Guest connectors monthly and inspect O-rings; replace if hardened or cracked. Sanitize assemblies with a food-safe sanitizer at manufacturer concentrations, rinse thoroughly, and allow parts to air dry before reassembly.
