Replace worn pilot components without downtime using this replacement pilot assembly, engineered for precise ignition control and straightforward installation. Designed for gas valve systems, this assembly restores consistent pilot performance and reduces service intervals. Technicians will find the part simple to mount and adjust, delivering reliable ignition in high-use kitchens.
LongDescription#@#NA#@@#Cleaning Instructions#@#Unplug gas appliances and shut fuel supply. Remove the Advance Tabco SU-P-102 pilot assembly per manufacturer steps. Clean pilot tip and tube with a soft brush and solvent safe for brass; clear obstructions. Inspect seals and fittings; replace damaged parts. Reassemble tight fittings to prevent leaks. Light pilot and monitor flame stability. Clean vents and grease traps regularly to reduce fire risk, lower energy use, and prevent contamination.#@@#Additional Info#@#Advance Tabco SU-P-102 Replacement Pilot Assembly features a direct-fit HF-G pilot tube and flash tube for commercial gas equipment, certified CSA, ensuring reliable ignition control.#@@#General Info#@#Description #@#
Replace worn pilot components without downtime using this replacement pilot assembly, engineered for precise ignition control and straightforward installation. Designed for gas valve systems, this assembly restores consistent pilot performance and reduces service intervals. Technicians will find the part simple to mount and adjust, delivering reliable ignition in high-use kitchens.
This assembly features a configuration suited for direct ignition paths, which improves flame stability and reduces misfires. Service teams will observe consistent pilot flame characteristics during repeated cycles.
Manufacturers specified materials to withstand thermal cycling and common kitchen conditions, which extends operational life. Field technicians report fewer premature failures compared with generic alternatives.
Design dimensions measure approximately 6 inches in height and 6 inches in width, which permits installation in confined valve compartments. Installers gain access and routing flexibility in tight mechanical layouts.
This unit carries CSA recognition, meeting regulatory criteria for gas ignition components used in commercial equipment. Facility managers can document compliance during safety audits.
OEM form and mounting points match legacy HF-G pilot assemblies, which reduces adjustment time during swaps. Maintenance staff will perform replacements with standard hand tools and minimal calibration.
Weighing approximately 1 pound, this assembly imposes minimal load on valve fittings and supports ease of handling during installation. Technicians benefit from reduced strain when servicing multiple units in a single shift.
#@@#Delivery Details#@#
• Please ensure to handle the product with utmost care.
• Check if the product you have received has all the essential parts and accessories.
• Make sure to examine the product for damage before signing the delivery receipt.
• Contact customer service for delivery concerns.
• Delivery times may vary based on location.#@@#deliverynotes#@#NA#@@#Maintenance Guide#@#Inspect the Advance Tabco SU-P-102 Replacement Pilot Assembly monthly for soot, corrosion, and loose fittings. Remove debris from the pilot tube and flame port with a soft brush; avoid metal scrapers. Verify thermocouple continuity and replace if resistance exceeds manufacturer limits. Tighten gas connections to specified torque and test for leaks using a soap solution. Calibrate flame height per Advance Tabco guidelines and document each service event.
